High Performance 22kw 8bar Scroll Oil Free Air Compressor Screw Type 27.5kw 33kw 10bar 3.6m3/min Industrial Air Compress Machine

Short Description:

5.5kw 11kw 16.5kw 22kw 27.5kw 33kw 38.5kw 44kw 49.5kw 55kw 8bar 10bar
oil free scroll air compressors PM VSD oil free scroll air comoressor
sroll Air Compressor For Plastic Machines Stationary Compressor low noise silentenergy saving
Industrial supply

Send email to us

Product Detail

OPPAIR factory introduction

OPPAIR customer feedback

OIL-FREE SCROLL AIR COMPRESSOR

Advantages:

1.Low noise, low vibration, and high energy efficiency,

2.Compact, modular, and compact design with 2-10 units, small size, and light weight, suitable for various operating conditions.

3.No oil or carbon pollution in the air, no risk of oil leaks, and no need for centralized condensate treatment, making it environmentally friendly and environmentally friendly.

4.No lubricant or oil filter replacement required, no wearingparts, and a long service life.

5.Low operating costs, zero emissions, and low power consumption.

Model	OFR-7PV	OFR-15PV	OFR-22PV	OFR-30PV	OFR-37PV	OFR-45PV	OFR-50PV	OFR-60PV	OFR-66PV	OFR-75PV
Power（kw）	5.5	11	16.5	22	27.5	33	38.5	44	49.5	55
Horsepower(hp)	7.5	15	22.5	30	37.5	45	52.5	60	67.5	75
Air displacement /Working pressure（m3/min./bar）	0.6/8	1.2/8	1.8/8	2.4/8	3.0/8	3.6/8	4.2/8	4.8/8	5.4/8	6.0/8
Air displacement /Working pressure（m3/min./bar）	0.51/10	1.02/10	1.53/10	2.04/10	2.55/10	3.06/10	3.57/10	4.08/10	4.59/10	5.1/10
Air outlet diamater	DN15	DN25	DN25	DN25	DN25	DN25	DN25	DN25	DN25	DN25
Control Mode	Pressure
Noise Level dB	63	64	66	66	67	67	67	68	68	68
Length（mm）	800	1100	1100	1300	1500	1420	1650	1650	1650	1650
Width（mm）	560	700	700	830	1180	1010	1550	1550	1550	1550
Height（mm）	880	1130	1500	1260	1700	1510	1950	1950	1950	1950
Weight（kg）	135	258	322	470	860	890	1160	1220	1250	1350
Model	OFR-7F	OFR-15F	OFR-22F	OFR-30F	OFR-37F	OFR-45F	OFR-50F	OFR-60F	OFR-66F	OFR-75F
Power（kw）	5.5	11	16.5	22	27.5	33	38.5	44	49.5	55
Horsepower(hp)	7.5	15	22.5	30	37.5	45	52.5	60	67.5	75
Air displacement /Working pressure（m3/min./bar）	0.6/8	1.2/8	1.8/8	2.4/8	3.0/8	3.6/8	4.2/8	4.8/8	5.4/8	6.0/8
Air displacement /Working pressure（m3/min./bar）	0.51/10	1.02/10	1.53/10	2.04/10	2.55/10	3.06/10	3.57/10	4.08/10	4.59/10	5.1/10
Air outlet diamater	DN15	DN25	DN25	DN32	DN40	DN40	DN40	DN40	DN40	DN40
Control Mode	Pressure
Noise Level dB	63	64	64	65	65	66	68	68	68	68
Length（mm）	680	1180	1180	1500	1500	1500	1650	1650	1650	1650
Width（mm）	640	760	760	1180	1180	1180	1550	1550	1550	1550
Height（mm）	960	1250	1690	1250	1690	1690	1500	1950	1950	1950
Weight（kg）	151	350	556	643	785	870	1201	1413	1330	1420
