High Pressure Booster Compressor 30bar 40bar Suit for Industrial Screw Air Compressor

Short Description:

The pressurized air compressor can pressurize the low-pressure air source to the high-pressure air source suitable for the blow molding machine. Compared with the traditional piston air compressor, it has the characteristics of low noise and high efficiency, and is especially suitable for large-flow application’s gas requirements

Send email to us

Product Detail

OPPAIR factory introduction

OPPAIR customer feedback

video

The pressurized air compressor can pressurize the low-pressure air source to the high-pressure air source suitable for the blow molding machine.Compared with the traditional piston air compressor,it has the characteristics of low noise and high efficiency,and is especially suitable for large-flow application's gas requirements.

Detailed View

BOOSTER AIR COMPRESSOR FOR BOTTLE BLOWING NEED TO MATCH 8/10BAR SCREWAIR COMPRESSOR

Model	SCH-1.5/30	SCH-2.4/30	SCH-3.2/30	SCH-5.0/30	SCH-6.0/30
Displacement(m³/min)	1.5	2.4	3.2	5.0	6.0
Exhaust pressure(bar)	30	30	30	30	30
Input pressure(bar)	8	8	8	8	8
Power(kw)	7.5	11	15	18.5	22
Overall dimensions L×W×H(mm)	1000×550×950	1350×800×1100	1350×800×1100	1350×800×1100	1450×950×1250
Weight(kg)	230	380	400	480	520

SCH-8.0/30	SCH-10.0/30	SCH-2.4/40	SCH-4/40	SCH-5/40	SCH-6/40	SCH-8/40	SCH-10/40
8.0	10.0	2.4	4.0	5.0	6.0	8.0	10.0
30	30	40	40	40	40	40	40
8	8	10	10	10	10	10	10
30	37	15	18.5	22	30	37	45
1500×950×1300	1600×1000×1400	1500×950×1300	1600×1000×1300	1600×1000×1300	1650×1000×1400	1800×1200×1500	1800×1200×1500
600	850	600	750	750	800	850	850

MEDIUM PRESSURE PISTONAIR COMPRESSOR CAN REACH 30/40/60BAR DIRECTLY FROM OBAR

Model	SCW-0.6/30(2)	SCW-1.0/30(2)	SCW-1.2/30(2)	SCW-1.6/30(3)	SCW-2.0/30(2)	2-SCW-2.4/30(2)
Displacement(m³/min)	0.6	1.0	1.2	1.6	2.0	2.4
Exhaust pressure(bar)	30	30	30	30	30	30
Compressed stage	Two-stage compression			Three-stage compression	Two-stage compression
Cooling way	Air cooled			Air cooled	Air cooled
Power	7.5	11	15	18.5	22	2*15
Speed(rmp)	780	750	780	800	800	780
Overall dimensions L×W×H(mm)	11005301020	11508001000	12008501150	13508501040	150013001000	180011001200
Weight(kg)	290	440	480	500	800	850

SCW-0.8140(3)	SCW-1.0/40(3)	SCW-1.2/40(3)	SCW-1.6140(3)	SCW-2.0/40(3)	SCW-0.6/60(3)	SCW-1.0/60(3)	SCW-1.6/60(3)
0.8	1.0	1.2	1.6	2.0	0.6	1.0	1.6
40	40	40	40	40	60	60	60
Three-stage compression

Air cooled
11	15	18.5	22	30	11	18.5	22
780	750	780	780	800	720	750	820
11508001100	12007501113	140010001100	13509001040	180013001200	12008501150	140010001100	180013001200
450	440	520	550	850	480	520	850
