to single-stage compression?
In recent years, energy-saving air compressors have become the main trend in market development, and two-stage permanent magnet variable frequency air compressors have also become the mainstream product in the industry. Below, OPPAIR will discuss the advantages of two-stage variable frequency air compressors compared to ordinary screw air compressors.
The air compressor design process involves natural air entering the compressor through an air filter, mixing with a small amount of lubricating oil in the compression chamber, and compressing the mixed gas to a certain pressure. The compressed gas enters the cooling channel, where it comes into contact with a large amount of oil mist, causing its temperature to decrease. The gas then enters the second rotor for secondary compression, further compressing it to the discharge pressure. Each compression stage in a screw air compressor has a low compression ratio, and the forces on the rotors and bearings are small. Coupled with the large rotor diameter and low speed, this results in stable operation. It features a unique main unit design. It combines the first and second compression rotors in a single casing and drives them directly through gears, allowing each rotor to achieve optimal linear velocity and higher compression power. OPPAIR two-stage compressor uses two sets of screw rotors of different sizes to achieve reasonable pressure distribution and reduce the compression ratio at each stage. This reduces internal leakage and increases volumetric efficiency.
Another advantage is that variable frequency compression significantly reduces the load on the bearings, increasing bearing life and extending the lifespan of the main unit. For air compressor users, the power consumption of air compressors accounts for approximately 10% to 50% of the total electricity consumption in a factory, making it one of the main factors in electricity costs and a good opportunity for businesses to reduce overall costs. Currently, more and more customers are realizing the importance of energy-saving air compressors and are turning to two-stage variable frequency air compressors. Choosing a low-energy-consumption air compressor will undoubtedly provide them with sustained benefits over the long term.
Compared to single-stage compression, two-stage compression approaches the energy-saving isothermal compression. In principle, two-stage compression saves 5-8% more energy than single-stage compression. Using a two-stage compressor means using two sets of screw rotors of different sizes to achieve reasonable pressure distribution and reduce the compression ratio at each stage. In addition, OPPAIR two-stage permanent magnet variable frequency air compressor uses a centrifugal cooling fan, which provides better suction and heat dissipation than traditional axial fans, resulting in lower noise. Furthermore, it utilizes variable frequency control, regulating the fan speed based on the exhaust temperature to suppress power waste and stabilize the system and overall component temperatures.
OPPAIR two-stage compression variable frequency air compressor also saves users considerable costs. Many users operate several air compressors in parallel. While using multiple machines in parallel is possible, it results in complex piping and control systems, a large footprint, numerous failure points, and high maintenance and electricity costs. OPPAIR two-stage compression permanent magnet variable frequency air compressor solves the problems of unstable air output and high control costs, further reducing production costs for customers.
In general, a single-stage compression air compressor can achieve the normal operating pressure required for typical power systems. However, from the perspective of energy consumption, using two-stage compression can effectively reduce energy consumption, resulting in higher efficiency and greater value in air usage.
OPPAIR is looking for global agents, welcome to contact us for inquiries:
WhatsApp: +86 14768192555
#Electric Rotary Screw air Compressor #Screw Air Compressor With Air Dryer #High Pressure Low Noise Two Stage Air Compressor Screw#All in one screw air compressors#Skid mounted laser cutting screw air compressor#oil cooling screw air compressor#oil free compressors
Post time: Dec-26-2025
