Fixed speed screw air compressors of the OPPAIR brand

Short Description:

Industrial Fixed speed screw air compressors are designed and engineered to produce the most efficient and effective performance possible. These Industrial compressors are specifically designed with the user in mind, ensuring that their products are easy to use and achieve more than expected. It’s very important for your plant to choose the right industrial compressor.

There are many choices to consider when looking to buy a new compressor for your industrial plant. The most common choices are reciprocating industrial air compressor screw type. The best choice depends on the size of your facility and how you use compressed air.


Product Detail

Product Tags

Fixed Speed Screw Air Compressor

Model OPP-10F OPP-15F OPP-20F OPP-30F OPP-40F OPP-50F OPP-60F OPP-75F
Power (kw) 7.5 11 15 22 30 37 45 55
Horsepower (hp) 10 15 20 30 40 50 60 75
Air displacement/
Working pressure
(M³/Min. / bar)
1.2 / 7 1.6 / 7 2.5 / 7 3.8 / 7 5.3 / 7 6.8 / 7 7.4 / 7 10.0 / 7
1.1 / 8 1.5/8 2.3/8 3.6 / 8 5.0 / 8 6.2 / 8 7.0 / 8 9.2 / 8
0.9 / 10 1.3 / 10 2.1 / 10 3.2 / 10 4.5 / 10 5.6 / 10 6.2 / 10 8.5 / 10
0.8 / 12 1.1 / 12 1.9 / 12 2.7 / 12 4.0 / 12 5.0 / 12 5.6 / 12 7.6 / 12
Air out
let diameter
DN20 DN25 DN25 DN25 DN40 DN40 DN40 DN50
Lubricating oil volume (L) 10 16 16 18 30 30 30 65
Noise level dB(A) 60±2 62±2 62±2 64±2 66±2 66±2 66±2 68±2
Driven method Direct driven
Type Fixed Speed
Start method Υ-Δ
Length (mm) 950 1150 1150 1350 1500 1500 1500 1900
Width (mm) 670 820 820 920 1020 1020 1020 1260
Height (mm) 1030 1130 1130 1230 1310 1310 1310 1600
Weight (kg) 250 400 400 550 700 750 800 1750
Model OPP-100F OPP-125F OPP-150F OPP-175F OPP-200F OPP-275F OPP-350F
Power (kw) 75.0 90 110 132 160 200 250
Horsepower (hp) 100 125 150 175 200 275 350
Air displacement/
Working pressure
(M³/Min. / bar)
13.4 / 7 16.2 / 7 21.0 / 7 24.5 / 7 32.4 / 7 38.2 / 7 45.5 / 7
12.6 / 8 15.0 / 8 19.8 / 8 23.2 / 8 30.2 / 8 36.9 / 8 43 / 8
11.2 / 10 13.8 / 10 17.4 / 10 20.5 / 10 26.9 / 10 33/ / 10 38.9 / 10
10.0 / 12 12.3 / 12 14.8 / 12 17.4 / 12 23 / 12 28.5 / 12 36 / 12
Air out
let diameter
DN50 DN50 DN65 DN65 DN75 DN90 DN90
Lubricating oil volume (L) 65 72 90 90 110 130 150
Noise level dB(A) 68±2 70±2 70±2 70±2 75±2 85±2 85±2
Driven method Direct driven
Type Fixed Speed
Start method Υ-Δ
Length (mm) 1900 2450 2450 2450 2760 2760 2760
Width (mm) 1260 1660 1660 1660 1800 1800 1800
Height (mm) 1600 1700 1700 1700 2100 2100 2100
Weight (kg) 1850 1950 2200 2500 2800 3100 3500

Product description

MOTOR

1. The motor uses high-performance motors of well-known brands. Permanent magnet synchronous motors (PM motors) use high-performance NdFeB permanentmagnets which will not lose magnetism under 200. and its service life reaches as long as 15 years.
2. The stator coil uses the frequency converter special halo proof enameled wire, theinsulation is outstanding and the service life is longer.
3. The motor has the function of temperature protection. It also has a wide range of motor speed regulation, high precision and wide range of volume regulation. The reliability is significantly improved with small size, low noise and large excess current.
4. Protection grade IP55, insulation grade F, efectively protects the motor and increases the serice life of the motor, the eficiency is 5% 7% higher than similar products.

MOTOR
fan

FAN

1. The fan uses a large fan design to effectively enhance the fan's heat dissipation effect.The motor adopts a special intermnal design to adapt to harsh working conditions.
2. The fan motor adopts specal winding and high protection grade design to adapt to harsh working conditions.
3. The fan is controlld by the controller to realie the automatic start and stop function, which efctively maintains the normal working temperature of the air compressor lubricant.

HEAT EXHANGER

1. The heat exchanger uses high-quality raw materials and a unique intemal channel design, which increases the heat exchange area and can effectively dissipate heat for the air compressor.
2. The inner wall of the heat exchanger is treated with corrosion protection to increase the service life of the heat exchanger and increase the heat transfer effect.
3. The radiator has passed the strict factory test, and the quality is reliable, which efetively prevents the high temperature of the air compressor and increases the service life of the machine.

HEAT EXHANGER
