In modern industrial sheet metal fabrication, fiber laser cutting technology has become the core driver of manufacturing productivity. However, high-quality, continuous cutting results rely heavily on the auxiliary gas supply. OPPAIR, a globally recognized industrial compressor manufacturer, proudly presents its heavy-duty Skid-Mounted Screw Air Compressor series engineered specifically for laser cutting applications, offering unmatched energy saving, high efficient performance, and whisper-quiet low noise operation across 16 bar and 20 bar operating pressures.
Whether you are operating compact fiber lasers or ultra-high-power cutting systems, OPPAIR provides the ideal Compressor for 1.5/3/6/12/20/30kw Laser machines, ensuring optimal cutting speed, clean edge finishes, and comprehensive protection for your valuable optical lenses.
Why Choose a Skid-Mounted Screw Air Compressor for Laser Cutting?
Traditional compressed air installations require separate compressors, standalone dryers, external storage tanks, complex interconnecting piping, and multiple filters. This scattered setup often leads to pressure drops, pipe leaks, contamination risks, and high installation costs.
The OPPAIR skid-mounted screw air compressor revolutionizes this process with an integrated, plug-and-play design built upon a heavy-duty unified base:
- PM VSD Energy Saving Technology: Equipped with an intelligent permanent magnet variable frequency (PM VSD) drive, the compressor dynamically modulates motor speed to match laser gas consumption in real time, saving up to 30% in electrical power compared to conventional fixed-speed units.
- Dual High-Efficiency Drying: Combines an energy-efficient plate-exchange refrigerated air dryer with a modular two-tower adsorption dryer to achieve ultra-low pressure dew points and prevent condensation in internal gas lines.
- Five-Stage CTAXF / CTAFH Precision Filtration: Multi-tier filtration removes dust, moisture, and residual oil down to 0.01 um and oil content to less than 0.003 ppm, thoroughly preventing lens contamination and optical nozzle degradation.
- Dual 600L Air Tanks (Total 1200L): A generous buffer capacity ensures rock-solid pressure stability, preventing pressure fluctuations even during continuous high-speed piercing and corner cutting.
- Low Noise Enclosure: Fully enclosed sound-dampening acoustic panels reduce operational noise to minimal levels, making the unit comfortable to place directly next to cutting workstations.
Tailored Compressor Solutions for 1.5kW to 30kW Laser Cutters
Different laser power levels and metal sheet thicknesses require distinct cutting pressures and air flow volumes. OPPAIR delivers targeted models to optimize your cutting efficiency:
1. Compressor for 1.5kW to 3kW Fiber Lasers
For thin-sheet precision processing (carbon steel, stainless steel, aluminum up to 3 mm), air consumption is relatively low. OPPAIR 16 bar skid-mounted units provide stable, dry air that replaces expensive bottled oxygen or nitrogen, cutting gas costs by over 70% while maintaining rapid processing speeds.
2. Compressor for 6kW to 12kW High-Power Lasers
Medium-to-high power laser cutting demands higher air flow and constant 16 bar pressure for clean, burr-free cuts on medium plates. OPPAIR Laser-30PV/16 (22kW / 30HP, 2.0 m3/min) and Laser-40PV/16 (30kW / 40HP, 3.4 m3/min) are the proven choices, capable of supporting continuous multi-shift production lines.
3. Compressor for 20kW, 30kW and Higher Ultra-Power Lasers
When tackling thick carbon steel (over 20 mm) or heavy stainless steel with 20kW to 30kW fiber lasers, gas assist pressure must reach 20 bar with massive flow. OPPAIR Laser-40PV/20 (30kW, 2.72 m3/min) and Laser-50PV/20 (37kW / 50HP, 3.4 m3/min) 20 bar skid-mounted systems provide continuous, high-pressure kinetic penetration for spotless bottom edge results without dross.
OPPAIR Skid-Mounted Laser Compressor Specifications
| Model | Power | Working Pressure | Air Supply Flow | Drive Type | Tank Capacity | Filtration Precision |
|---|---|---|---|---|---|---|
| Laser-30PV/16 | 22 kW (30 HP) | 16 bar | 2.0 m3/min (70.6 cfm) | PM VSD | 2 * 600L (1200L) | 0.001 um (5-Stage) |
| Laser-40PV/16 | 30 kW (40 HP) | 16 bar | 3.4 m3/min (119 cfm) | PM VSD | 2 * 600L (1200L) | 0.001 um (5-Stage) |
| Laser-50PV/16 | 37 kW (50 HP) | 16 bar | 4.5 m3/min (157.5 cfm) | PM VSD | 2 * 600L (1200L) | 0.001 um (5-Stage) |
| Laser-30PV/20 | 22 kW (30 HP) | 20 bar | 1.57 – 1.92 m3/min | PM VSD | 2 * 600L (1200L) | 0.001 um (5-Stage) |
| Laser-40PV/20 | 30 kW (40 HP) | 20 bar | 2.72 m3/min (95.2 cfm) | PM VSD | 2 * 600L (1200L) | 0.001 um (5-Stage) |
| Laser-50PV/20 | 37 kW (50 HP) | 20 bar | 3.4 m3/min (119 cfm) | PM VSD | 2 * 600L (1200L) | 0.001 um (5-Stage) |
Engineered for Demanding Industrial Environments
Beyond metal fabrication and laser workshops, OPPAIR’s robust skid-mounted architecture is engineered to withstand 24/7 heavy-duty operation in demanding industrial conditions, including high-temperature facilities, energy processing plants, and heavy manufacturing sites requiring high-pressure stability and explosion-proof reliability.
About OPPAIR
Shandong OPPAIR Machinery Manufacturing Co., Ltd. and OPPAIR Compressor (Shanghai) Co., Ltd. represent one of China’s most trusted manufacturers of industrial rotary screw compressors. With products exported to over 100 countries and territories worldwide, OPPAIR compressors adhere to strict international quality standards certified by CE, SGS, ASME, TUV, and ISO9001.
Standard delivery lead time is 30 days, backed by a comprehensive 18-month overall warranty and up to 3-year warranty for IP65 PM VSD core assemblies.
